ITEM

Description

Connector

SATA 7Pin connector

Connector Contact

SAS connector as defined in SFF-8482

Connector Configuration

29-Pin Connector

Connector Termination Style

Right Angel

No. of HSIO Routed

Surface Mount

RF Co-axial Launch Connector

2 TX and 2 RX

HSIO Routing

2.92mm Connector -50 Ohm

Board Stack-Up

50 Ohm ±5% Single-Ended Stripline

De-embedding structure

4 Layers (1.52mm thickness)

Reference plane for 2X THRU

De-embedding structure

2X THRU Line

Power source to DUT

40mils from void
